Tutorial¶

Who is this tutorial for?¶

People on the Galaxy team who want to see the NOMAD ↔ Galaxy round trip work for themselves, without needing a NOMAD deployment — Part 1 covers this.
NOMAD plugin developers or users who want to try the full round trip through a real NOMAD deployment — Part 2 covers this.

What should you should know before this tutorial?¶

You should be familiar with the general idea of the NOMAD ↔ Galaxy demonstrator. General knowledge of both NOMAD and Galaxy is also helpful

What you will know at the end of this tutorial?¶

You will know

how to invoke the Galaxy peak finding workflow with and without NOMAD

Throughout this tutorial you'll be running find_peaks, the one NOMAD Action this plugin currently implements: it sends an XPS spectrum to Galaxy for peak finding and links the annotated result back into NOMAD. It's an example Action, not the only kind possible — the underlying NOMAD Actions interface is generic, and find_peaks is here to demonstrate the NOMAD ↔ Galaxy round trip end to end, concretely. See What this plugin does for the broader picture.

Part 1: check the Galaxy round trip, no NOMAD required¶

This is the fastest way to see the whole NOMAD → Galaxy → NOMAD interaction actually work, and the part most relevant if you're on the Galaxy team and don't have a NOMAD deployment handy — everything here runs against real usegalaxy.eu, using the same code (galaxy_client.py) the real NOMAD Action uses, with no NOMAD or Temporal involved at all.

You'll need uv and a usegalaxy.eu API key (Galaxy GUI: User → Preferences → Manage API Key).

Clone this repo and cd into it.
Store your API key where the standalone scripts can find it, without it ending up anywhere it shouldn't (shell history, chat logs, etc.):

echo "GALAXY_API_KEY=your-key-here" > .env

.env is already gitignored.

Import the XPS peak finding workflow into your account. This only needs to be done once — it checks for an existing copy by name first, so re-running it is safe:

uv run --env-file .env scripts/import_workflow.py

This prints a workflow_id. Add it to .env:

echo "GALAXY_WORKFLOW_ID=the-id-just-printed" >> .env

Run the round trip against the bundled example spectrum (examples/galaxy_demo/example_data/vms_regular_ref.nxs):

uv run --env-file .env scripts/test_galaxy_roundtrip.py

Expect output like:

Uploading vms_regular_ref.nxs and invoking workflow ...
  history_id=... invocation_id=...
Polling...
  [0s] state=running done=False
  ...
  [65s] state=ok done=True
Outputs: {'output_nxs': '...', 'peaks_tabular': '...', 'peaks_json': '...'}
Downloaded annotated NeXus to .../scripts/roundtrip_result.nxs

You can pass a different spectrum file as an argument if you want to try your own:

uv run --env-file .env scripts/test_galaxy_roundtrip.py path/to/your_spectrum.nxs

Note: an occasional run may fail with a Galaxy compute-cluster error unrelated to this plugin (a transient container-cache issue, e.g. image format not recognized from Singularity/CVMFS) — this has been observed to be transient; retrying the same command usually succeeds.

Inspect the result. roundtrip_result.nxs is a copy of the input with peaks added under /<entry>/fit as an NXfit group (h5py, pynx read, or any NeXus browser works):

uv run --with h5py python -c "
import h5py
with h5py.File('scripts/roundtrip_result.nxs') as f:
    entry = next(iter(f.keys()))
    fit = f[f'{entry}/fit']
    print(fit.attrs['NX_class'], list(fit.keys()))
"

Part 2: the full round trip through NOMAD¶

This part needs a running NOMAD deployment with this plugin installed (see Install This Plugin) and an XPS entry already in it (for example, converted by pynxtools-xps).

Don't have an NXxps file handy? On the Uploads page, Add example uploads includes XPS Peak Finding via Galaxy (a ready-to-use spectrum) so you can skip straight to step 3 below.

Bring up Temporal and a CPU action worker (from the nomad-distro-dev repo root):

docker compose up -d
uv run poe cpuworker

Open the XPS spectrum's entry in the NOMAD GUI and copy its entry_id from the overview page.
In the main menu, open Actions and start a new run of find_peaks_action (or use the Run action button on the upload itself). NOMAD auto-generates the form from the workflow's own input model — fill in spectrum_entry_id (from step 2), a Galaxy API key, and optionally prominence/distance/height, then run it. (Triggering happens here, through NOMAD's generic Actions form, rather than through a bespoke schema entry — see Explanation for why.)
Watch its status in the Actions view move to COMPLETED. Behind the scenes this is running exactly the same steps as Part 1, plus reading the spectrum from NOMAD's upload storage first and writing the result back into NOMAD's upload storage last.
A new entry now exists in the upload: the original spectrum's data, with peaks added as an NXfit/NXpeak group, fully searchable like any other NOMAD quantity.
